DIY Aluminium Picket Fence Panel 2185mm wide

DIY Aluminium Picket Fence Panel

Create a clean vertical frontage with a FENLUX DIY aluminium picket fence panel. This modular fencing system is suitable for modern front fences, side boundaries and selected light commercial projects across Australia.

The panel is supplied as a flat-pack DIY kit and can be adjusted during assembly to suit the required finished width. Matching pedestrian gates, sliding gates, aluminium fence posts and accessories are available for coordinated fencing projects.

Is This Fence Panel Suitable for Your Project?

This panel may suit your project if you need:

• A modern aluminium fence with clean vertical picket lines
• A modular panel that can be shortened during assembly
• Flexibility for final fitting between installed fence posts
• A DIY fence kit suitable for assembly with standard tools
• Matching fence panels, pedestrian gates and driveway gates

Trim the Panel to Suit the Final Opening

The aluminium rails and pickets can be shortened onsite, allowing the finished panel width to be adjusted to suit the measured opening between posts. This is useful when post spacing or final site measurements differ slightly from the original project plan.

Components can be shortened but cannot be extended. Confirm the opening width, fence height and post positions before cutting or assembling the panel.

Choose Screw Fix or Rivet Fix Assembly

This aluminium picket fence panel is available with either screw fixing or rivet fixing. Select the assembly method that best suits your project and preferred installation process.

Screw Fix

The screw-fix version uses screws to secure the pickets to the rails. The rails and pickets do not contain the same pre-drilled rivet fixing positions, providing greater flexibility when selecting where components are shortened onsite.

Rivet Fix

The rivet-fix version has pre-drilled rivet holes in the rails and pickets. If the panel needs to be shortened, plan the cut within a gap section wherever possible to avoid leaving an unused pre-drilled hole exposed near the finished edge.

Cutting position should be planned before assembly. Review the relevant assembly instructions and product measurements before making permanent cuts.

DIY Assembly and Site Installation

This product is supplied as a DIY fence panel kit and requires assembly. FENLUX provides assembly guidance and video support to help customers understand the panel construction and fixing process.

Assembly may be completed by customers with suitable tools and practical DIY experience. Site installation is a separate stage and depends on the fence layout, post foundations, ground conditions and selected fixing method. Professional installation may be appropriate where the site requires additional preparation or structural work.

Key Features

• DIY aluminium picket fence panel kit
• Clean vertical picket design
• Adjustable finished width
• 10mm standard spacing between pickets
• Available with screw-fix or rivet-fix assembly
• Powder-coated aluminium construction
• Suitable for residential and selected light commercial fencing
• Matching gates, posts and accessories available

Suitable Applications

• Front yard fencing
• Residential boundary fencing
• Side fence runs
• Modern home frontage projects
• Selected light commercial fencing

Build a Coordinated Aluminium Fence System

Combine this picket fence panel with matching FENLUX products to create a consistent design across the property frontage. Compatible options include aluminium fence posts, pedestrian gates and driveway gates in the same vertical picket style.

• Matching aluminium pedestrian gates
• Matching sliding driveway gates
• Compatible aluminium fence posts
• Brackets, caps and related accessories

Explore our aluminium pedestrian gates, aluminium driveway gates and fence and gate accessories.

What Is Included?

• 65 x 16mm aluminium pickets
• 40 x 50mm U-shape aluminium rails with strip covers
• Four brackets with screws
• Picket fixings for the selected assembly version
• Plastic picket caps

Please note: Assembly is required. Fence posts, concrete, tools and site-specific installation hardware are not included unless clearly stated on the product page.

Product Specifications

• Picket size: 65 x 16mm
• Rail size: 40 x 50mm
• Standard picket gap: 10mm
• Material: Powder-coated aluminium alloy
• Nominal component width: 2185mm
• Finished width including brackets: Approximately 2195mm
• Available colours: White, Grey and Black
• Assembly options: Screw Fix or Rivet Fix

Product dimensions and available configurations may vary by selected variant. Confirm the chosen colour, height and assembly method before placing your order.

Frequently Asked Questions

Is this fence panel suitable for DIY assembly?

Yes. The panel is supplied as a DIY kit and requires assembly. Customers should review the assembly guidance and confirm they have suitable tools and practical experience before beginning.

Can the panel be shortened onsite?

Yes. The aluminium rails and pickets can be shortened to achieve the required finished width. Measure carefully and plan all cutting positions before assembly.

Can the panel be extended?

No. The supplied components can be shortened but are not designed to be extended. Select a panel configuration that is at least as wide as the required finished opening.

What is the difference between screw fixing and rivet fixing?

Screw fixing secures the pickets using screws and allows more freedom when choosing a cutting position. Rivet-fix panels have pre-drilled rivet holes in the rails and pickets, so onsite cuts should preferably be made within a gap section to avoid exposing unused holes.

Are fence posts included?

No. Fence posts are generally purchased separately so the correct post size, length and quantity can be selected for the site.

Are matching gates available?

Yes. Matching aluminium pedestrian gates and driveway gates are available in the same vertical picket style.

Can this panel be used for a complete front fence?

Yes. Multiple panels can be combined with matching posts and gates to create a coordinated residential front fence system.
